Applicable Printing material and advantage
-This Cl Flexo Printing Machine Is Suitable for Roll to Roll Printing Plastic Film, Paper, Non Woven Fabric, PP Woven Fabric, Aluminum Foil, And Other Similar Roll Type Materials.
-The high print quality and registration accuracy of CI (central impression) Flexo printing is well established, presses are now able to compete with flexographicoard packaging manufacturing, We offer solutions to varied requirement of different customers, with different models, from entry level to top level
-There have been significant advances in flexographic printing in the past few years. At higher resolutions and faster speeds, flexo is now more competitive with offset and rotogravure. The Indian industry has begun to grasp the numerous advantages of CI flexo that include lower start up waste, faster changeovers, economical handling of shorter runs and high-speed printing. People see flexo as a modern, cost-effective process for printing of flexible materials
Basic parameters
| Model | XHCI-E |
| Material width | 600-2500mm) |
| Printing width | 570-2460mm |
| Printing length | 320-800mm |
| Roller diameter | Ф1200mm |
| Machine speed | 50-260m/min |
| Printing speed | 50-250m/min Depend on the materials |
| Register precision | ±0.15mm |
| Register type | Electric comt |
| Printing colors | 4 colors to 14 colors |
| Weight | Depending on the model |
| Dimension | Depending on the model |
| Voltage | 3phase 380V 50HZ |
Features & Benefits
1Method:Central impression for better color registration. With the central impression configuration,theprinted material is supported by the cylinder,and greatly improving color registration, especially with extensible materials.
2.Structure: Wherever possible, parts are communized for availability and wear-resisting design.
3.Dryer: Hot wind dryer, automatic temperature controller, and separated heat source.
4.Doctor blade: Chamber doctor blade type assembly for high-speed printing.
5.Transmission: Hard gear surface, high precision Decelerate Motor, and encoder buttons are placed on both control chassis and body for operations convenience.
6.Rewind: Micro Decelerate Motor, drive Magnetic Powder and Clutch, with PLC control tension stability.
7.Gearing of Printing cylinder: repeat length is 5MM.
8.Machine Frame: 100MM thick iron plate. No vibration at high speed and have a long service life.
Machine details pictures
About our company
FAQ
